EDL 2Inch Threaded Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg

Name: EDL 2Inch Threaded Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg
Brand: Guangzhou EDL Casters Co.,Ltd.
SKU: M612P-13
Availability: InStock

Brand Name:	EDL
Model Number:	M612P-13
MOQ:	1pcs
Price:	Negotiate
Payment Terms:	T/T
Supply Ability:	30,000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, RoHS

Name:

Equipment Casters

Wheel Diameter:

3inch

Tread Material:

Mounting Height:

103.5mm

Mounting Type:

Plate Swivel/Brake

Frame Material:

Cold-Rolled Plate

Plate Thickness:

4.5mm

Bracket Thickness:

3mm

Surface Treatment:

Zinc Coating

Bracket Width:

51mm

Wheel Width:

45mm

Bearing:

Bolt

Tread Color:

Black

Applicable Temperature:

-20℃～80℃

Tread Hardness:

67D

Packaging Details:

Carton

Supply Ability:

30,000pcs/day

Product Description

EDL 2Inch Threaded Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg

The EDL M623P-03 2-inch threaded equipment caster is designed for reliable performance in light to medium-duty applications. It features a threaded stem mounting, making installation simple and secure on a wide range of equipment, carts, and mobile devices.

The wheel is manufactured from PO (Polyolefin) material, which is environmentally friendly, non-toxic, and compliant with general sustainability requirements. PO wheels offer good hardness, stable rolling performance, and resistance to wear under daily use, making them suitable for factories, warehouses, workshops, and commercial equipment.

With a maximum load capacity of 180kg, this caster provides dependable support while maintaining smooth mobility. Available in rigid, swivel, and swivel with brake options, it allows flexible configuration to meet different movement and locking requirements.

This caster is an ideal choice for customers seeking a cost-effective, durable, and eco-friendly wheel solution for equipment mobility.

Wheel ltem No.Instruction

Wheel

Item No.

Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

Core

Tread

Bearing

Applicable

Temperature

Hardness

M623-03

75mm

45mm

51mm

180Kg

Bolt

-20℃～80℃

67D

EDL 2Inch Threaded Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg 0

EDL 2Inch Threaded Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg 2

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.

EDL 2Inch Threaded Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg 4
