EDL 2Inch Plate Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg

Name: EDL 2Inch Plate Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg
Brand: Guangzhou EDL Casters Co.,Ltd.
SKU: M612P-13
Availability: InStock

Brand Name:	EDL
Model Number:	M612P-13
MOQ:	1pcs
Price:	Negotiate
Payment Terms:	T/T
Supply Ability:	30,000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, RoHS

Name:

Equipment Casters

Wheel Diameter:

3inch

Tread Material:

Mounting Height:

103.5mm

Mounting Type:

Plate Swivel/Brake

Frame Material:

Cold-Rolled Plate

Plate Thickness:

4.5mm

Bracket Thickness:

3mm

Surface Treatment:

Zinc Coating

Bracket Width:

51mm

Wheel Width:

45mm

Bearing:

Bolt

Tread Color:

Black

Applicable Temperature:

-20℃～80℃

Tread Hardness:

67D

Packaging Details:

Carton

Supply Ability:

30,000pcs/day

Product Description

EDL 2Inch Plate Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg

The EDL 2 Inch Plate Equipment Caster M623P-03 is designed for reliable and efficient equipment mobility in light to medium-duty applications. Made from high-quality PO (polyolefin) material, the wheel offers good wear resistance, low rolling resistance, and stable performance on various industrial floors.

With a load capacity of 180 kg per caster, it provides dependable support for carts, equipment bases, and storage units. The plate mounting design ensures secure installation and compatibility with a wide range of equipment structures.

Available in rigid, swivel, and swivel brake configurations, this caster allows smooth movement and precise control. Its simple structure, durability, and cost-effective performance make it a practical choice for everyday industrial and commercial use.

Wheel ltem No.Instruction

Wheel

Item No.

Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

Core

Tread

Bearing

Applicable

Temperature

Hardness

M623-03

75mm

45mm

51mm

180Kg

Bolt

-20℃～80℃

67D

EDL 2Inch Plate Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg 0

EDL 2Inch Plate Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg 2

EDL 2Inch Plate Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg 4

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.

EDL 2Inch Plate Equipment Casters M623P-03 By Rigid Swivel Brake Load 180kg 6
