EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type

Name: EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type
Brand: Guangzhou EDL Casters Co.,Ltd.
SKU: M4125P-16
Availability: InStock

Brand Name:	EDL
Model Number:	M4125P-16
MOQ:	1pcs
Price:	Negotiate
Payment Terms:	T/T
Supply Ability:	30,000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, RoHS

Name:

Equipment Casters

Wheel Diameter:

2.5inch(65mm)

Tread Material:

Mounting Type:

Rigid/Swivel/Brake

Dynamic Load:

300kg

Mounting Height:

85mm

Frame Material:

Cold-Rolled Plate

Plate Thickness:

2mm

Bracket Thickness:

2mm

Surface Treatment:

Zinc Coating

Bracket Width:

41mm

Wheel Width:

35mm

Bearing:

Double Ball Bearings

Tread Color:

Black

Applicable Temperature:

-20℃～100℃

Tread Hardness:

67D

Packaging Details:

Carton

Supply Ability:

30,000pcs/day

Highlight:

2.5 Inch Plate Casters

2.5 inch heavy equipment casters

Brake Type heavy equipment casters

Product Description

EDL Equipment Casters 2.5 Inch Plate Casters M4125P-16 by Rigid,Swive,Brake Type

The EDL 2.5-Inch Plate Equipment Caster (Model M4125P-16) is built to meet the demands of high-load industrial applications, offering enhanced mobility and durability. Crafted from premium black nylon (PA), it resists wear, deformation, and impact, making it well-suited for both static and dynamic heavy-duty use. With a load rating of up to 250kg, it ensures dependable support for larger machines, workstations, or mobile platforms. The caster comes in rigid, swivel, and brake options, providing versatile movement control depending on operational needs. Its plate mounting system allows for firm attachment to flat equipment bases, while the slightly larger 2.5-inch wheel diameter improves ground clearance and rolling ease. Designed with a focus on both safety and performance, this caster helps lower the equipment’s center of gravity for better balance during transport. Whether used in workshops, labs, or production facilities, the M4125P-16 combines strength and adaptability to meet the demands of industrial mobility.

Wheel ltem No.Instruction

Wheel

Item No.

Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

Core

Tread

Bearing

Applicable

Temperature

Hardness

M4125-16

2.5"

65mm

35mm

41mm

300Kg

Double ball

bearing 6001

-20℃～100℃

67D

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type 0

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type 2

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type 4

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type 6

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type 7
