EDL TPU Equipment Casters 2.5 Inch Threaded Casters 300Kg Road With Brake M4125S-86A

Name: EDL TPU Equipment Casters 2.5 Inch Threaded Casters 300Kg Road With Brake M4125S-86A
Brand: Guangzhou EDL Casters Co.,Ltd.
SKU: M4125S-86A
Availability: InStock

Brand Name:	EDL
Model Number:	M4125S-86A
MOQ:	1pcs
Price:	Negotiate
Payment Terms:	T/T
Supply Ability:	30,000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, RoHS

Name:

Equipment Casters

Wheel Diameter:

2.5inch(65mm)

Tread Material:

TPU

Core Material:

Aluminum

Dynamic Load:

300kg

Mounting Height:

91mm

Frame Material:

Cold-Rolled Plate

Standard Threaded:

M12×25

Bracket Thickness:

2mm

Surface Treatment:

Zinc Coating

Bracket Width:

41mm

Wheel Width:

35mm

Bearing:

Double Ball Bearings

Tread Color:

Brown

Applicable Temperature:

-30℃～80℃

Tread Hardness:

92A

Packaging Details:

Carton

Supply Ability:

30,000pcs/day

Highlight:

TPU Equipment Casters

2.5 Inch Threaded Casters

300Kg Road Threaded Casters

Product Description

EDL TPU Equipment Casters 2.5 Inch Threaded Casters 300Kg Road with Brake M4125S-86A

The EDL 2.5-Inch Threaded Equipment Caster with Brake features a premium-grade TPU tread bonded to a high-strength aluminum alloy core, manufactured using advanced casting technology. This process enhances durability, structural stability, and impact resistance, making the caster suitable for long-term use under heavy-duty industrial conditions.

TPU (thermoplastic polyurethane) offers excellent shock absorption, low rolling noise, and smooth mobility, even over uneven surfaces. It protects sensitive flooring and minimizes vibration transfer to the equipment—ideal for workplaces where both performance and quiet operation matter. The wheel also resists wear, cracking, and deformation, making it a superior alternative to standard rubber or plastic casters.

This caster has a larger 2.5-inch diameter and a low-profile design that improves balance and load distribution, particularly for heavy equipment. It’s fitted with a sturdy M12×25 threaded stem for stable mounting and easy installation. With a load capacity of up to 300kg per caster, it’s an optimal choice for equipment that demands both durability and precision handling.

Wheel ltem No.Instruction

Wheel

Item No.

Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

Core

Tread

Bearing

Applicable

Temperature

Hardness

M4125-86A

2.5"

65mm

35mm

41mm

300Kg

Aluminum

TPU

Double ball

bearing 6001

-30℃～80℃

92A

EDL TPU Equipment Casters 2.5 Inch Threaded Casters 300Kg Road With Brake M4125S-86A 0

EDL TPU Equipment Casters 2.5 Inch Threaded Casters 300Kg Road With Brake M4125S-86A 2

EDL TPU Equipment Casters 2.5 Inch Threaded Casters 300Kg Road With Brake M4125S-86A 4

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.

EDL TPU Equipment Casters 2.5 Inch Threaded Casters 300Kg Road With Brake M4125S-86A 5
