EDL 5Inch Stainless Steel Threaded Caster Loading 150Kg With TPU Wheel S545S-85

Name: EDL 5Inch Stainless Steel Threaded Caster Loading 150Kg With TPU Wheel S545S-85
Brand: Guangzhou EDL Casters Co.,Ltd.
SKU: S545S-85
Availability: InStock

Brand Name:	EDL
Model Number:	S545S-85
MOQ:	1pcs
Price:	Negotiate
Payment Terms:	T/T
Supply Ability:	30,000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, RoHS

Wheel Diameter:

5inch(125mm)

Tread Material:

TPU

Dynamic Load:

150kg

Mounting Type:

Threaded Swivel/Brake

Mounting Height:

161mm

Frame Material:

304# Stainless Steel

Threaded Size:

M12*25

Bracket Thickness:

2.5mm

Bracket Width:

41mm

Wheel Width:

32mm

Bearing:

Derlin

Tread Color:

Red

Applicable Temperature:

-20℃～80℃

Tread Hardness:

95A

Packaging Details:

Carton

Supply Ability:

30,000pcs/day

Highlight:

5 inch stainless steel caster

threaded caster with TPU wheel

heavy duty caster 150kg

Product Description

EDL 5Inch Stainless Steel Threaded Caster Loading 150Kg With TPU Wheel S545S-85

The EDL 5-Inch Stainless Steel Threaded Caster S545S-85 is a durable and versatile caster featuring a vibrant red TPU wheel. Designed with a stainless steel threaded stem, it allows for secure installation on a wide range of equipment. Each caster supports up to 150 kg, providing smooth, quiet, and stable movement even under heavy loads.Available in both swivel (with brake) and rigid versions, this caster is ideal for industrial trolleys, medical carts, laboratory instruments, and food service equipment. The TPU wheel offers excellent shock absorption, floor protection, and long-lasting durability, making it suitable for frequent use across different surfaces.The stainless steel construction ensures corrosion and rust resistance, allowing reliable performance in humid, chemical, or demanding environments. With its 5-inch wheel size, the caster enhances maneuverability and obstacle-crossing capability, combining strength, functionality, and a modern aesthetic. The EDL 5-Inch Threaded Red TPU Caster is a dependable solution for commercial, industrial, and laboratory applications.

Wheel ltem No.Instruction

Wheel

Item No.

Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

Core

Tread

Bearing

Applicable

Temperature

Hardness

S545S-85

125mm

32mm

41mm

150KG

TPU

Derlin

-20℃～80℃

95A

EDL 5Inch Stainless Steel Threaded Caster Loading 150Kg With TPU Wheel S545S-85 0

EDL 5Inch Stainless Steel Threaded Caster Loading 150Kg With TPU Wheel S545S-85 2

EDL 5Inch Stainless Steel Threaded Caster Loading 150Kg With TPU Wheel S545S-85 4

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.
