EDL 3Inch Stainless Steel Medium Duty Caster With Durable Wheel Loading 150Kg S543P-75

Name: EDL 3Inch Stainless Steel Medium Duty Caster With Durable Wheel Loading 150Kg S543P-75
Brand: Guangzhou EDL Casters Co.,Ltd.
SKU: S543P-75
Availability: InStock

Brand Name:	EDL
Model Number:	S543P-75
MOQ:	1pcs
Price:	Negotiate
Payment Terms:	T/T
Supply Ability:	30,000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, RoHS

Wheel Diameter:

3inch(75mm)

Tread Material:

TPU

Dynamic Load:

150kg

Mounting Type:

Rigid/Swivel/Brake

Mounting Height:

107mm

Frame Material:

304# Stainless Steel

Plate Thickness:

3mm

Bracket Thickness:

2.5mm

Bracket Width:

41mm

Wheel Width:

32mm

Bearing:

Derlin

Tread Color:

Grey

Applicable Temperature:

-20℃～80℃

Tread Hardness:

95A

Packaging Details:

Carton

Supply Ability:

30,000pcs/day

Product Description

EDL 3Inch Stainless Steel Medium Duty Caster With Durable Wheel Loading 150Kg S543P-75

The EDL 3-Inch Stainless Steel Medium Duty Caster S543P-75 is a high-quality wheel designed for versatility and strength. Built with a durable TPU wheel, it combines the elasticity of rubber with the toughness of metal, offering excellent shock absorption, floor protection, and quiet rolling performance. Each caster supports up to 150 kg, making it ideal for a wide range of equipment such as medical devices, food service carts, laboratory instruments, and industrial trolleys.

The stainless steel housing ensures outstanding corrosion resistance, allowing the caster to perform reliably even in humid or chemical environments. Whether used indoors or outdoors, it maintains smooth movement and long service life. Designed for stability, durability, and easy maneuverability, this EDL caster provides an excellent mobility solution for both commercial and industrial applications.

Wheel ltem No.Instruction

Wheel

Item No.

Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

Core

Tread

Bearing

Applicable

Temperature

Hardness

S543P-75

75mm

32mm

41mm

150KG

TPU

Derlin

-20℃～80℃

95A

EDL 3Inch Stainless Steel Medium Duty Caster With Durable Wheel Loading 150Kg S543P-75 0

EDL 3Inch Stainless Steel Medium Duty Caster With Durable Wheel Loading 150Kg S543P-75 2

EDL 3Inch Stainless Steel Medium Duty Caster With Durable Wheel Loading 150Kg S543P-75 4

EDL 3Inch Stainless Steel Medium Duty Caster With Durable Wheel Loading 150Kg S543P-75 6

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.

EDL 3Inch Stainless Steel Medium Duty Caster With Durable Wheel Loading 150Kg S543P-75 7
