EDL Medium Duty Zinc Coating 3inch 130kg Threaded TPU Caster by Swivel and Brake type 5713S-77

Name: EDL Medium Duty Zinc Coating 3inch 130kg Threaded TPU Caster by Swivel and Brake type 5713S-77
Brand: Guangzhou EDL Casters Co.,Ltd.
SKU: 5713S-77
Availability: InStock

Brand Name:	EDL
Model Number:	5713S-77
MOQ:	1pcs
Price:	Negotiate
Payment Terms:	T/T
Supply Ability:	30,000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, RoHS

Wheel Diameter:

3inch(75mm)

Dynamic Load:

130kg

Core Material:

Tread Material:

TPU

Mounting Type:

Swivel / Brake

Mounting Height:

121mm

Frame Material:

Cold-Rolled Plate

Surface Treatment:

Zinc Coating

Standard Threaded:

M12×25

Bracket Thickness:

2.5mm

Bracket Width:

41mm

Wheel Width:

31mm

Bearing:

Single Ball Bearing

Tread Color:

Grey

Applicable Temperature:

-20℃～80℃

Tread Hardness:

95A

Name:

Industrial Caster Wheels

Packaging Details:

Carton

Supply Ability:

30,000pcs/day

Highlight:

threaded industrial caster wheels

threaded industrial heavy duty caster wheels

medium duty industrial caster wheels

Product Description

EDL Medium Duty Zinc Coating 3inch 130kg Threaded TPU Caster by Swivel and Brake type 5713S-77

The EDL Medium Duty Zinc Coating 3-inch 130kg Threaded TPU Caster by Swivel and Brake type 5713S-77 is designed for durability and performance in medium-duty applications. Made from high-quality gray TPU, this caster offers superior wear resistance, elasticity, and floor protection compared to standard materials. The single ball bearing ensures smooth movement, while the threaded stem mounting provides a secure and stable installation. Featuring a plastic dual brake system for reliable stopping power, this caster also includes a 2.5mm thick zinc-coated bracket, enhancing structural strength and corrosion resistance for long-lasting use in various environments.

Wheel ltem No.Instruction

Wheel

Item No.

Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

Core

Tread

Bearing

Applicable

Temperature

Hardness

5713-77

75mm

31mm

41mm

130Kg

TPU

Single ball

bearing 6002

-20℃～80℃

95A

EDL Medium Duty Zinc Coating 3inch 130kg Threaded TPU Caster by Swivel and Brake type 5713S-77 0

EDL Medium Duty Zinc Coating 3inch 130kg Threaded TPU Caster by Swivel and Brake type 5713S-77 2

EDL Medium Duty Zinc Coating 3inch 130kg Threaded TPU Caster by Swivel and Brake type 5713S-77 4

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.

EDL Medium Duty Zinc Coating 3inch 130kg Threaded TPU Caster by Swivel and Brake type 5713S-77 5
