EDL Medium Duty 5inch 150kg Yellow TPU Threaded Caster by Swivel and Brake type 505S-86A

Name: EDL Medium Duty 5inch 150kg Yellow TPU Threaded Caster by Swivel and Brake type 505S-86A
Brand: Guangzhou EDL Casters Co.,Ltd.
SKU: 505S-86A
Availability: InStock

Brand Name:	EDL
Model Number:	505S-86A
MOQ:	1pcs
Price:	Negotiate
Payment Terms:	T/T
Supply Ability:	30,000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, RoHS

Wheel Diameter:

5inch(125mm)

Dynamic Load:

150kg

Core Material:

Aluminum

Tread Material:

TPU

Mounting Type:

Swivel / Brake

Standard Threaded:

M16×25

Mounting Height:

169mm

Frame Material:

Cold-Rolled Plate

Surface Treatment:

Zinc Coating

Bracket Thickness:

2.5mm

Bracket Width:

41mm

Wheel Width:

32mm

Bearing:

Double Ball Bearings

Tread Color:

Yellow

Applicable Temperature:

-20℃～80℃

Tread Hardness:

92A

Name:

Industrial Caster Wheels

Packaging Details:

Carton

Supply Ability:

30,000pcs/day

Highlight:

threaded industrial caster wheels

threaded industrial heavy duty caster wheels

medium duty industrial caster wheels

Product Description

EDL Medium Duty 5inch 150kg Yellow TPU Threaded Caster by Swivel and Brake type 505S-86A

EDL Medium Duty 5-inch 150kg Yellow TPU Aluminum Core Threaded Caster 505S-86A This caster features a high-strength aluminum core, offering superior load-bearing capacity and durability compared to traditional plastic cores. It resists deformation under heavy loads, ensuring an extended lifespan. The aluminum material also provides excellent corrosion resistance, making it ideal for industrial and commercial applications. The wheel surface is made of premium yellow TPU, delivering exceptional wear resistance, noise reduction, and impact absorption while protecting floors and minimizing vibrations. A dual ball bearing system enhances smooth rolling and reduces friction for improved maneuverability. The threaded stem design ensures a secure and stable installation on various equipment. With a 5-inch diameter, this caster offers increased clearance and adaptability for different surfaces, making it suitable for medium-duty applications. Additionally, it features both a pedal brake and an iron dual brake system, ensuring reliable stopping power and enhanced safety in diverse working environments.

Wheel ltem No.Instruction

Wheel

Item No.

Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

Core

Tread

Bearing

Applicable

Temperature

Hardness

505-86A

125mm

32mm

41mm

150Kg

Aluminum

TPU

Double ball

bearing 6001

-30℃～80℃

92A

EDL Medium Duty 5inch 150kg Yellow TPU Threaded Caster by Swivel and Brake type 505S-86A 0

EDL Medium Duty 5inch 150kg Yellow TPU Threaded Caster by Swivel and Brake type 505S-86A 2

EDL Medium Duty 5inch 150kg Yellow TPU Threaded Caster by Swivel and Brake type 505S-86A 4

EDL Medium Duty 5inch 150kg Yellow TPU Threaded Caster by Swivel and Brake type 505S-86A 6

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.
